| Typ brzdového kotúča | plný |
| Povrch | potiahnutá |
| Vonkajżí priemer [mm] | 246 |
| Hrúbka brzd. kotúča (mm) | 13 |
| Výżka [mm] | 34 |
| Ráfik, počet dier | 4 |
| Rozstupová krużnica Ø [mm] | 108 |
| Centrovací priemer [mm] | 66 |
| Kontrolná značka | ECE R90 APPROVED |
| Minimálna hrúbka (mm) | 11 |
| Hmotnosť [kg] | 3,74 |
| Rozmiestnenie otvorov/Počet otvorov | 6/4 |
| Značka | Číslo |
|---|---|
| A.B.S. | 16920 OE |
| A.B.S. | 16920 |
| ACDelco | AC2181D |
| AP | 14833 E |
| ASHUKI by Palidium | 149-888A |
| ATE | 24.0113-0185.1 |
| BARUM | BAR13185 |
| BENDIX | 562055BC |
| BORG & BECK | BBD4098 |
| BOSCH | 0 986 478 887 |
| BRECO | BS 7654 |
| BREMBO | 08.9606.14 |
| CAR | HPD 534 |
| CAR | 142.534 |
| CIFAM | 800-486 |
| CITROËN/PEUGEOT | 4246.R9 |
| CITROËN/PEUGEOT | 4246.R8 |
| CITROËN/PEUGEOT | 4249.A5 |
| COMLINE | ADC1508 |
| DELPHI | BG3364 |
| DENCKERMANN | B130061 |
| DJ PARTS | BD1185 |
| E.T.F. | 19-4298 |
| EUROBRAKE | 5815201926 |
| FARCOM | 230869 |
| FEBI BILSTEIN | 11105 |
| FERODO | DDF995C-1 |
| FREMAX | BD-4298 |
| fri.tech. | BD0210 |
| FTE | BS4740 |
| GIRLING | 6028153 |
| GRAF | DF29486 |
| HELLA | 8DD 355 106-191 |
| HELLA PAGID | 8DD 355 106-191 |
| ICER | 78BD4298 C |
| ICER | 78BD4298-2 |
| JP GROUP | 4163102809 |
| JURID | 562055JC |
| KAGER | 37-0161 |
| KAMOKA | 1031990 |
| KAWE | 6535 00 |
| KLAXCAR FRANCE | 25022z |
| KRAFT AUTOMOTIVE | 6045770 |
| LEMFÖRDER | 22835 02 |
| LPR | C1341P |
| MAGNETI MARELLI | 360406040803 |
| MAGNETI MARELLI | 360406040800 |
| MAPCO | 15429 |
| METELLI | 23-0486 |
| METZGER | 6535.00 |
| METZGER | 6110085 |
| METZGER | 14721 E |
| MEYLE | 11-15 521 0024 |
| MINTEX | MDC1010 |
| National | NBD946 |
| NK | 311926 |
| OPEN PARTS | BDA1671.10 |
| OPEN PARTS | BDR1671.10 |
| OPTIMAL | BS-5350 |
| PAGID | 52516PRO |
| PAGID | 52516 |
| PEX | 14.0462 |
| PILENGA | 5097 |
| PROTECHNIC | PRD1125 |
| QH Benelux | HP57793 |
| QUINTON HAZELL | BDC4740 |
| RAMEDER | T0620678 |
| REMSA | 6535.00 |
| ROADHOUSE | 6535.00 |
| ROULUNDS BRAKING | D2181 |
| SASIC | 2464R84J |
| sbs | 1815311926 |
| SIMER | D1025 |
| ST-TEMPLIN | 01.18.42.121145 |
| SWAG | 62 91 1105 |
| TEXTAR | 92092803 |
| TOPRAN | 721 175 |
| TRISCAN | 8120 28111 |
| TRUSTING | DF210 |
| TRW | DF2815 |
| VAICO | V42-40012 |
| VALEO | 186598 |
| VEMA | 98012 |
| WAGNER | WGR0995-1 |
| WOKING | D6535.00 |
| ZIMMERMANN | 180.3014.52 |
| ZIMMERMANN | 180.3014.00 |
| Model | Rok | Kód motora | KW | CCM |
|---|---|---|---|---|
CITROËN |
||||
CITROËN XSARA (N1) |
||||
| 1.4 i | 1997 - 2005 | KFW (TU3JP), KFX (TU3JP) | 55 | 1360 |
| 1.5 D | 1997 - 2000 | VJZ (TUD5) | 42 | 1527 |
CITROËN XSARA Break (N2) |
||||
| 1.4 i | 1997 - 2005 | KFW (TU3JP), KFX (TU3JP) | 55 | 1360 |
| 1.5 D | 1997 - 2000 | VJZ (TUD5) | 42 | 1527 |
| 1.6 i | 1997 - 2000 | NFZ (TU5JP) | 65 | 1587 |
| 1.8 D | 1997 - 2000 | A9A (XUD7) | 43 | 1769 |
| 1.9 D | 1997 - 2000 | DJY (XUD9A) | 50 | 1905 |
| 1.9 D | 1998 - 2000 | DHV (XUD9BSD) | 55 | 1905 |
| 1.9 D | 1998 - 2005 | WJY (DW8B), WJZ (DW8) | 51 | 1868 |
CITROËN XSARA Coupe (N0) |
||||
| 1.4 i | 1998 - 2005 | KFW (TU3JP), KFX (TU3JP) | 55 | 1360 |
PEUGEOT |
||||
PEUGEOT 206 SW (2E/K) |
||||
| 1.1 | 2002 - 2007 | HFX (TU1JP) | 44 | 1124 |
| 1.4 | 2002 - 2007 | KFV (TU3A), KFW (TU3JP) | 55 | 1360 |
| 1.4 16V | 2003 - súčasnosť | KFU (ET3J4) | 65 | 1360 |
| 1.4 HDi | 2002 - 2007 | 8HX (DV4TD) | 50 | 1398 |
PEUGEOT 206 Schrägheck (2A/C) |
||||
| 1.1 | 1998 - 2000 | HFY (TU1JP) | 40 | 1124 |
| 1.1 i | 1998 - 2007 | HFX (TU1JP), HFZ (TU1JP) | 44 | 1124 |
| 1.4 i | 1998 - 2012 | KFW (TU3A), KFW (TU3JP), KFX (TU3JP) | 55 | 1360 |
| 1.6 i | 1998 - 2000 | NFZ (TU5JP) | 65 | 1587 |
| 1.9 D | 1998 - 2001 | WJY (DW8B), WJZ (DW8) | 51 | 1868 |
PEUGEOT 206 Stufenheck |
||||
| 1.4 | 2007 - súčasnosť | KFV (TU3A), KFW (TU3JP) | 55 | 1360 |
