| Obmedzenie výrobcu | BOSCH |
| żírka [mm] | 102,3 |
| Výżka [mm] | 48,4 |
| Hrúbka [mm] | 16,5 |
| Výstrażný kontakt opotrebenia | bez pripravy pre ukazovatel opotrebenia |
| Doplnkový tovar/ Dopňujúca informácia 2 | so skrutkami brzdoveho strmena |
| Doplnkový tovar/ Dopňujúca informácia | s prislusenstvom |
| Kontrolná značka | E9 90R - 01120/1666 |
| Značka | Číslo |
|---|---|
| A.B.S. | 37597 |
| AISIN | BPCI-2004 |
| APEC | PAD1526 |
| ATE | 13047038362 |
| ATE | 13046038362 |
| Bendix | DB2041 |
| BENDIX | 573194B |
| BORG & BECK | BBP2029 |
| BOSCH | 0986494199 |
| BOSCH | 0 986 494 622 |
| BOSCH | 0986TB2980 |
| BOSCH | 0 986 TB2 980 |
| BOSCH | 0 986 494 199 |
| BOSCH | 0986494622 |
| BOSCH | 0 986 495 448 |
| Brake ENGINEERING | PA1688 |
| BREMBO | P61085N |
| BREMBO | P61085 |
| CITROËN | 425432 |
| CITROËN | 4253 71 |
| CITROËN | 16 478 737 80 |
| CITROËN | 4254 32 |
| CITROËN | 16 111 410 80 |
| CITROËN | 425371 |
| DELPHI | LP2055 |
| DELPHI | LP2055-18B1 |
| FEBI BILSTEIN | 16793 |
| FERODO | FDB1973 |
| FERODO | FSL1973 |
| FIRST LINE | FBP3558 |
| FREMAX | FBP-1579 |
| FTE | 9010798 |
| FTE | 9005074 |
| GIRLING | 6116924 |
| HELLA | 8DB355013361 |
| HELLA | 8DB 355 013-361 |
| HELLA PAGID | 8DB 355 013-361 |
| JURID | 573194J |
| LPR | 05P1475 |
| METELLI | 2208010 |
| METZGER | 124100 |
| MEYLE | 025 245 4016 |
| MEYLE | 0252454016 |
| MGA | 867 |
| MINTEX | MDB2892 |
| NK | 221957 |
| PAGID | T1703 |
| QH Benelux | 7797 |
| QUINTON HAZELL | BP1562 |
| REMSA | 124100 |
| REMY | RAP1200 |
| ROULUNDS RUBBER | 845381 |
| sbs | 221957 |
| SWAG | 64916793 |
| TEXTAR | 2454016414 |
| TEXTAR | 2454001 |
| TRISCAN | 811038007 |
| TRUSTING | 8170 |
| VALEO | 598798 |
| VALEO | 670936 |
| VALEO | 598936 |
| VALEO | 302214 |
| WAGNER | WBP24540A |
| WOKING | P1341300 |
| Model | Rok | Kód motora | KW | CCM |
|---|---|---|---|---|
CITROËN |
||||
CITROËN C4 GRAND PICASSO I (UA_) |
||||
| 1.6 16V | 2008 - 2010 | 5FT (EP6DT) | 103 | 1598 |
| 1.6 16V | 2008 - 2013 | 5FX (EP6DT) | 110 | 1598 |
| 1.6 HDi | 2006 - 2011 | 9HY (DV6TED4), 9HZ (DV6TED4) | 80 | 1560 |
| 1.6 HDi 110 | 2010 - 2013 | 9HR (DV6C) | 82 | 1560 |
| 1.6 THP 155 | 2010 - 2013 | 5FV (EP6CDT) | 115 | 1598 |
| 1.6 VTi 120 | 2008 - 2013 | 5FS (EP6C), 5FW (EP6) | 88 | 1598 |
| 1.8 i 16V | 2006 - 2010 | 6FY (EW7A) | 92 | 1749 |
| 1.8 i 16V CNG | 2009 - 2011 | 86 | 1749 | |
| 1.8 i 16V Flex | 2009 - 2013 | 6FY (EW7A) | 86 | 1749 |
| 2.0 HDi 138 | 2006 - 2013 | RHJ (DW10BTED4), RHR (DW10BTED4) | 100 | 1997 |
| 2.0 HDi 150 | 2009 - 2013 | RHE (DW10CTED4) | 110 | 1997 |
| 2.0 HDi 165 | 2010 - 2013 | RHH (DW10CTED4) | 120 | 1997 |
| 2.0 i 16V | 2006 - 2013 | RFJ (EW10A) | 103 | 1997 |
CITROËN C4 PICASSO I Großraumlimousine (UD_) |
||||
| 1.6 16V | 2008 - 2013 | 5FX (EP6DT) | 110 | 1598 |
| 1.6 HDi | 2007 - 2013 | 9HY (DV6TED4), 9HZ (DV6TED4) | 80 | 1560 |
| 1.6 HDi 110 | 2010 - 2013 | 9HR (DV6C) | 82 | 1560 |
| 1.6 THP 140 | 2008 - 2013 | 5FT (EP6DT) | 103 | 1598 |
| 1.6 THP 155 | 2010 - 2013 | 5FV (EP6CDT) | 115 | 1598 |
| 1.6 VTi 120 | 2008 - 2013 | 5FW (EP6) | 88 | 1598 |
| 1.8 Bifuel | 2009 - 2012 | 6FY (EW7A) | 92 | 1749 |
| 1.8 i 16V | 2007 - 2011 | 6FY (EW7A) | 92 | 1749 |
| 2.0 HDi 138 | 2006 - 2013 | RHJ (DW10BTED4), RHR (DW10BTED4) | 100 | 1997 |
| 2.0 HDi 150 | 2009 - 2013 | RHE (DW10CTED4) | 110 | 1997 |
| 2.0 HDi 165 | 2010 - 2013 | RHH (DW10CTED4) | 120 | 1997 |
| 2.0 i 16V | 2007 - 2013 | RFJ (EW10A) | 103 | 1997 |
| 2.0 i 16V | 2008 - 2013 | RFN (EW10J4) | 105 | 1997 |
CITROËN C4 PICASSO II |
||||
| 2.0 i 16V | 2013 - 2014 | 105 | 1997 | |
