| Typ brzdového kotúča | s vnútorným chladením |
| Vonkajżí priemer [mm] | 278 |
| Hrúbka brzd. kotúča (mm) | 25 |
| Minimálna hrúbka (mm) | 23 |
| Počet dier | 5 |
| Rozstupová krużnica Ø [mm] | 108 |
| Výżka [mm] | 48,5 |
| Centrovací priemer [mm] | 63,6 |
| Kontrolná značka | 90R-02C0187/0010 |
| Značka | Číslo |
|---|---|
| A.B.S. | 18272 |
| ASHIKA | 60-00-0349 |
| ASHUKI by Palidium | P330-111 |
| ATE | 24.0125-0203.1 |
| BLUE PRINT | ADF124359 |
| BORG & BECK | BBD5304 |
| BOSCH | 0 986 479 699 |
| COMLINE | ADC1926V |
| FEBI BILSTEIN | 105718 |
| FERODO | DDF2509C |
| GIRLING | 6065361 |
| HELLA | 8DD 355 119-491 |
| HELLA | 8DD 355 126-561 |
| HELLA PAGID | 8DD 355 126-561 |
| HELLA PAGID | 8DD 355 119-491 |
| JURID | 563160JC |
| LPR | V1018V |
| METELLI | 23-1475C |
| METZGER | 6110811 |
| MEYLE | 515 521 0006 |
| MEYLE | 515 521 0006/PD |
| MINTEX | MDC2528 |
| NK | 204863 |
| NK | 314863 |
| NUOVA TECNODELTA | 142.1913 |
| REMSA | 61588.10 |
| ROADHOUSE | 61588.10 |
| sbs | 1815204863 |
| sbs | 1815314863 |
| TEXTAR | 92292303 |
| TEXTAR | 92255503 |
| TRISCAN | 8120 27150 |
| TRISCAN | 8120 27150C |
| TRUSTING | DF1698 |
| TRW | DF6536 |
| VOLVO | 31341642 |
| VOLVO | 31381374 |
| WINHERE BRAKE | YH21476 |
| ZIMMERMANN | 610.3720.20 |
| Model | Rok | Kód motora | KW | CCM |
|---|---|---|---|---|
VOLVO |
||||
VOLVO V40 Schrägheck (525) |
||||
| D2 | 2012 - 2016 | D 4162 T | 84 | 1560 |
| D2 | 2015 - 2019 | D 4204 T13, D 4204 T8 | 88 | 1969 |
| D3 | 2012 - 2015 | D 5204 T6 | 110 | 1984 |
| D3 | 2015 - 2019 | D 4204 T16, D 4204 T9 | 110 | 1969 |
| D4 | 2012 - 2014 | D 5204 T4 | 130 | 1984 |
| D4 | 2014 - 2019 | D 4204 T14 | 140 | 1969 |
| T2 | 2015 - 2019 | B 4204 T17, B 4204 T38 | 90 | 1969 |
| T2 | 2015 - 2019 | B 4154 T3, B 4154 T5 | 90 | 1498 |
| T2 GTDi | 2013 - 2016 | B 4164 T4 | 88 | 1596 |
| T3 | 2015 - 2019 | B 4204 T33, B 4204 T37 | 112 | 1969 |
| T3 | 2015 - 2019 | B 4154 T2, B 4154 T4 | 112 | 1498 |
| T3 GTDi | 2012 - 2016 | B 4164 T3 | 110 | 1596 |
| T4 GTDi | 2012 - 2016 | B 4164 T | 132 | 1596 |
| T5 | 2012 - 2014 | B 5254 T12 | 187 | 2497 |
| T5 | 2013 - 2015 | B 5204 T9 | 157 | 1984 |
| T5 | 2014 - 2019 | B 4204 T11, B 4204 T41 | 180 | 1969 |
VOLVO V40 Cross Country (526) |
||||
| T4 AWD | 2014 - 2019 | B 4204 T21 | 140 | 1969 |
| T5 AWD | 2012 - 2016 | B 5254 T12 | 187 | 2497 |
| T5 AWD | 2014 - 2019 | B 4204 T11, B 4204 T41 | 180 | 1969 |
