| Prevedenie palubnej siete | pre vozidla s 12 V napätim palubnej siete |
| Napätie [V] | 14 |
| Nabíjací prúd alternátora [A] | 150 |
| Remenica | s remenicou pre rebrovany klinovy remen |
| Počet rebier | 6 |
| Remenica Ø [mm] | 54 |
| Svorka | B+ M8 |
| Prevedenie zastrcky-ID | L / DFM |
| Značka | Číslo |
|---|---|
| BOSCH | 0 124 525 034 |
| BOSCH | 0 986 047 360 |
| CEVAM | CA1674IR |
| CEVAM | TG15C119 |
| CEVAM | 2542925 |
| CEVAM | 8EL011710661 |
| CEVAM | AL2291 |
| CEVAM | 542705 |
| CEVAM | AEK2878 |
| CEVAM | TECA30191 |
| CEVAM | 8660000670 |
| CEVAM | TAL0013 |
| CEVAM | 2451241402 |
| CEVAM | 542472 |
| CEVAM | 824ST65 |
| CEVAM | A3074PR |
| CEVAM | SG15C031 |
| CEVAM | 200283 |
| CEVAM | 50102319 |
| CEVAM | 626131 |
| CEVAM | A14VI40 |
| CEVAM | RPS401654 |
| CEVAM | 12047360 |
| CEVAM | 439696 |
| CEVAM | A0268 |
| CEVAM | LRA2228 |
| CEVAM | 437472 |
| CEVAM | LRA02228 |
| CEVAM | FRA408 |
| CEVAM | 010581 |
| CEVAM | 3190100400 |
| CEVAM | DRA4214X |
| CEVAM | 284995 |
| CEVAM | 9213167 |
| CEVAM | 8EL738003001 |
| CEVAM | TG15C054 |
| CEVAM | 542839 |
| CEVAM | 8EL011710651 |
| CEVAM | AL02558 |
| CEVAM | 2542704A |
| CEVAM | AEC1674 |
| CEVAM | TC8105 |
| CEVAM | 2542472A |
| CEVAM | 542557 |
| CEVAM | 8660000639 |
| CEVAM | SG15S017 |
| CEVAM | 2291311502 |
| CEVAM | 747134 |
| CEVAM | A3074 |
| CEVAM | SB140 |
| CEVAM | 1870998 |
| CEVAM | 4847360 |
| CEVAM | RAA15325 |
| CEVAM | 113755 |
| CEVAM | 439503 |
| CEVAM | 1012112540 |
| CEVAM | L69910 |
| CEVAM | 0986047360 |
| CEVAM | 3650A |
| CEVAM | FG15C156 |
| CEVAM | DRA4214 |
| CEVAM | 284702 |
| CEVAM | 9090243 |
| CEVAM | DRA0191 |
| CEVAM | TG15C156 |
| CEVAM | 2542925A |
| CEVAM | 542925 |
| CEVAM | AL2528 |
| CEVAM | TG15C022 |
| CEVAM | 2542757A |
| CEVAM | 8EL011360131 |
| CEVAM | AL02319 |
| CEVAM | TECA34214 |
| CEVAM | 2542704 |
| CEVAM | 542704 |
| CEVAM | 8671018438 |
| CEVAM | A3074SR |
| CEVAM | TC6105 |
| CEVAM | 2542472 |
| CEVAM | 8660000637 |
| CEVAM | 2291201502 |
| CEVAM | 50102558 |
| CEVAM | 746139 |
| CEVAM | A24702 |
| CEVAM | S11415007 |
| CEVAM | 12090024 |
| CEVAM | 440281 |
| CEVAM | A1166 |
| CEVAM | QA4334 |
| CEVAM | 1042104270 |
| CEVAM | LRA02878 |
| CEVAM | 437436 |
| CEVAM | IR6561 |
| CEVAM | 0124525034 |
| CEVAM | 3190100409 |
| CEVAM | EAA211006R |
| CEVAM | 301674RI |
| CEVAM | 934214 |
| CEVAM | VA586 |
| CEVAM | 56824 |
| CITROËN/PEUGEOT | 5705HC |
| CITROËN/PEUGEOT | 5705AL |
| CITROËN/PEUGEOT | 9646476280 |
| CITROËN/PEUGEOT | 57056P |
| CITROËN/PEUGEOT | 5702ES |
| CITROËN/PEUGEOT | 9640088280 |
| CITROËN/PEUGEOT | 5702A7 |
| CITROËN/PEUGEOT | 5705EW |
| CITROËN/PEUGEOT | 9648477580 |
| CITROËN/PEUGEOT | 5705AC |
| CITROËN/PEUGEOT | 9646068880 |
| CITROËN/PEUGEOT | 5702K6 |
| CITROËN/PEUGEOT | 96460668 |
| CITROËN/PEUGEOT | 5702C6 |
| CITROËN/PEUGEOT | 5702A6 |
| CITROËN/PEUGEOT | 5705NE |
| CITROËN/PEUGEOT | 5705ES |
| CITROËN/PEUGEOT | 9646477580 |
| CITROËN/PEUGEOT | 57058G |
| CITROËN/PEUGEOT | 5702F3 |
| CITROËN/PEUGEOT | 9646049980 |
| CITROËN/PEUGEOT | 5702C5 |
| DA SILVA | 010581 |
| DELCO REMY | DRA4197 |
| DELCO REMY | DRA4214 |
| DENSO | 104210-4270 |
| DENSO | 101211-2540 |
| DENSO | 101211-9230 |
| EAI | 56824 |
| ELSTOCK | 28-4702 |
| FIAT | 9646066880 |
| FIAT | 9639396480 |
| HELLA | 8EL 011 710-661 |
| HELLA | 8EL 011 710-651 |
| HOLGER CRISTIANSEN | CA1674IR |
| HOLGER CRISTIANSEN | 8EL738003-001 |
| HOLGER CRISTIANSEN | 8EL738211-221 |
| LANCIA | 9646066888 |
| LUCAS ELECTRICAL | LRA2228 |
| SUZUKI | 31400-73J00 |
| TOYOTA | 27060-YV020 |
| VALEO | 542925 |
| VALEO | TG15C 054 |
| VALEO | 2542705 |
| VALEO | 2542704 |
| VALEO | 542704 |
| VALEO | 437436 |
| VALEO | VA586 |
| VALEO | 2542925 |
| VALEO | TG15C 022 |
| VALEO | 542705 |
| VALEO | 542472 |
| VALEO | 626131 |
| VALEO | A14VI 40 |
| VALEO | 437472 |
| VALEO | 542839 |
| VALEO | 542557 |
| VALEO | SG15S 017 |
| VALEO | 437575 |
| Model | Rok | Kód motora | KW | CCM |
|---|---|---|---|---|
CITROËN |
||||
CITROËN C3 I (FC_, FN_) |
||||
| 1.4 16V HDi | 2002 - 2008 | 8HY (DV4TED4) | 66 | 1398 |
| 1.4 HDi | 2003 - 2011 | 8HZ (DV4TD) | 52 | 1398 |
| 1.4 HDi | 2002 - 2009 | 8HX (DV4TD), 8HZ (DV4TD) | 50 | 1398 |
| 1.4 HDi | 2005 - 2009 | 8HX (DV4TD) | 55 | 1398 |
CITROËN C2 (JM_) |
||||
| 1.4 HDi | 2003 - 2009 | 8HX (DV4TD), 8HZ (DV4TD) | 50 | 1398 |
| 1.4 HDi | 2003 - 2005 | 8HX (DV4TD) | 51 | 1398 |
CITROËN XSARA (N1) |
||||
| 1.4 HDi | 2003 - 2005 | 8HX (DV4TD) | 50 | 1398 |
| 2.0 HDi 109 | 2001 - 2005 | RHZ (DW10ATED) | 80 | 1997 |
| 2.0 HDi 90 | 1999 - 2005 | RHY (DW10TD) | 66 | 1997 |
CITROËN XSARA Coupe (N0) |
||||
| 1.4 HDi | 2003 - 2005 | 8HX (DV4TD) | 50 | 1398 |
| 2.0 HDi 109 | 2001 - 2005 | RHZ (DW10ATED) | 80 | 1997 |
| 2.0 HDI 90 | 1999 - 2005 | RHY (DW10TD) | 66 | 1997 |
CITROËN XSARA Break (N2) |
||||
| 1.4 HDi | 2003 - 2005 | 8HX (DV4TD) | 50 | 1398 |
| 2.0 HDi 109 | 2001 - 2005 | RHZ (DW10ATED) | 80 | 1997 |
| 2.0 HDI 90 | 1999 - 2005 | RHY (DW10TD) | 66 | 1997 |
CITROËN C3 Pluriel (HB_) |
||||
| 1.4 HDi | 2004 - súčasnosť | 8HX (DV4TD), 8HZ (DV4TD) | 50 | 1398 |
CITROËN C1 (PM_, PN_) |
||||
| 1.4 HDi | 2005 - 2014 | 8HT (DV4TD) | 40 | 1398 |
CITROËN C2 ENTERPRISE (JG_) |
||||
| 1.4 HDi | 2006 - 2009 | 8HX (DV4TD) | 50 | 1398 |
| 1.4 HDi | 2003 - 2005 | 8HZ (DV4TD) | 51 | 1398 |
CITROËN XSARA PICASSO (N68) |
||||
| 1.6 HDi | 2005 - 2011 | 9HX (DV6ATED4) | 66 | 1560 |
| 2.0 HDi | 1999 - 2011 | RHY (DW10TD) | 66 | 1997 |
CITROËN BERLINGO / BERLINGO FIRST Kasten/Großraumlimousine (M_) |
||||
| 1.6 HDI 75 (MB9HW) | 2005 - 2011 | 9HW (DV6BTED4), DV6B | 55 | 1560 |
| 1.6 HDI 90 (MB9HX, MC9HX) | 2005 - 2011 | 9HX (DV6ATED4) | 66 | 1560 |
| 2.0 HDI 90 (MBRHY, MCRHY) | 1999 - 2011 | RHY (DW10TD) | 66 | 1997 |
| 2.0 HDI 90 4WD (MBRHY, MCRHY) | 2000 - 2005 | RHY (DW10TD) | 66 | 1997 |
CITROËN BERLINGO / BERLINGO FIRST Großraumlimousine (MF_, GJK_, GFK |
||||
| 1.6 HDI 75 (MF9HW, GJ9HWC, GF9HWC, GN9HWC) | 2005 - 2011 | 9HW (DV6BTED4), DV6B | 55 | 1560 |
| 1.6 HDI 90 (MF9HX) | 2005 - 2008 | 9HX (DV6ATED4) | 66 | 1560 |
| 2.0 HDi 4x4 (MFRHY) | 2002 - 2005 | RHY (DW10TD) | 66 | 1997 |
| 2.0 HDI 90 (MFRHY) | 1999 - 2005 | RHY (DW10TD) | 66 | 1997 |
CITROËN C5 II (RC_) |
||||
| 1.8 16V (RC6FZB) | 2004 - 2005 | 6FZ (EW7J4) | 85 | 1749 |
| 2.2 HDi (RC4HXE) | 2004 - 2008 | 4HX (DW12TED4) | 98 | 2179 |
CITROËN C5 II Break (RE_) |
||||
| 1.8 16V (RE6FZB) | 2004 - 2005 | 6FZ (EW7J4) | 85 | 1749 |
| 2.2 HDi (RE4HXE) | 2004 - 2006 | 4HX (DW12TED4) | 98 | 2179 |
CITROËN C5 II Kasten/Kombi (RE_) |
||||
| 1.8 16V (RE6FZB) | 2004 - 2005 | 6FZ (EW7J4) | 85 | 1749 |
CITROËN C8 (EA_, EB_) |
||||
| 2.0 | 2002 - súčasnosť | RFN (EW10J4) | 100 | 1997 |
| 2.2 | 2002 - súčasnosť | 3FZ (EW12J4) | 116 | 2230 |
CITROËN C4 Coupe (LA_) |
||||
| 2.0 16V | 2004 - 2010 | RFK (EW10J4S) | 130 | 1997 |
CITROËN XSARA Kasten/Kombi |
||||
| 2.0 HDi | 2000 - 2005 | RHY (DW10TD) | 66 | 1997 |
CITROËN XSARA Kasten/Schrägheck (N3_) |
||||
| 2.0 HDi | 2000 - 2005 | RHY (DW10TD) | 66 | 1997 |
CITROËN C5 III (RD_) |
||||
| 2.2 HDi (RD4HTH) | 2008 - 2011 | 4HS (DW12BTED4) | 125 | 2179 |
FIAT |
||||
FIAT ULYSSE (179_) |
||||
| 2.0 (179BXA11, 179BXA1A) | 2002 - 2011 | RFN (EW10J4) | 100 | 1997 |
LANCIA |
||||
LANCIA PHEDRA (179_) |
||||
| 2.0 (179AXA11, 179AXA1A) | 2002 - 2010 | RFN (EW10J4) | 100 | 1997 |
PEUGEOT |
||||
PEUGEOT 206 Van |
||||
| 1.4 HDi | 2001 - 2009 | 8HX (DV4TD), 8HZ (DV4TD) | 50 | 1398 |
PEUGEOT 307 (3A/C) |
||||
| 1.4 HDi | 2001 - 2005 | 8HX (DV4TD), 8HZ (DV4TD) | 50 | 1398 |
| 1.6 16V | 2000 - 2007 | NFU (TU5JP4) | 80 | 1587 |
| 2.0 16V | 2000 - 2005 | RFN (EW10J4) | 100 | 1997 |
| 2.0 16V | 2005 - 2007 | RFJ (EW10A) | 103 | 1997 |
| 2.0 16V | 2005 - 2007 | RFK (EW10J4S) | 130 | 1997 |
PEUGEOT 206 SW (2E/K) |
||||
| 1.4 HDi | 2002 - 2007 | 8HX (DV4TD) | 50 | 1398 |
| 2.0 16V | 2002 - 2007 | RFN (EW10J4) | 100 | 1997 |
| 2.0 HDi | 2002 - 2007 | RHY (DW10TD) | 66 | 1997 |
PEUGEOT 307 Break (3E) |
||||
| 1.4 HDi | 2002 - 2005 | 8HZ (DV4TD) | 50 | 1398 |
| 1.6 16V | 2002 - 2008 | NFU (TU5JP4) | 80 | 1587 |
| 2.0 | 2002 - 2005 | RFN (EW10J4) | 100 | 1997 |
| 2.0 16V | 2005 - 2008 | RFJ (EW10A) | 103 | 1997 |
| 2.0 16V | 2005 - 2008 | RFK (EW10J4S) | 130 | 1997 |
PEUGEOT 1007 (KM_) |
||||
| 1.4 HDi | 2005 - súčasnosť | 8HX (DV4TD), 8HZ (DV4TD) | 50 | 1398 |
PEUGEOT 107 (PM_, PN_) |
||||
| 1.4 HDi | 2005 - 2014 | 8HT (DV4TD) | 40 | 1398 |
PEUGEOT 206 Schrägheck (2A/C) |
||||
| 1.4 HDi | 2002 - 2007 | 8HX (DV4TD) | 51 | 1398 |
| 1.4 HDi eco 70 | 2001 - 2009 | 8HX (DV4TD), 8HZ (DV4TD) | 50 | 1398 |
| 2.0 RC | 2003 - 2007 | RFK (EW10J4S) | 130 | 1997 |
| 2.0 S16 | 1999 - 2000 | RFR (EW10J4) | 99 | 1997 |
| 2.0 S16 | 1999 - 2007 | RFN (EW10J4) | 100 | 1997 |
PEUGEOT 307 SW Kasten/Kombi (3E_, 3H_) |
||||
| 1.4 HDi | 2002 - 2005 | 8HZ (DV4TD) | 51 | 1398 |
PEUGEOT 206 Stufenheck |
||||
| 1.4 HDi eco 70 | 2008 - súčasnosť | 8HZ (DV4TD) | 50 | 1398 |
PEUGEOT 307 SW (3H) |
||||
| 1.6 16V | 2002 - 2008 | NFU (TU5JP4) | 80 | 1587 |
| 2.0 16V | 2002 - 2005 | RFN (EW10J4) | 100 | 1997 |
| 2.0 16V | 2005 - 2008 | RFJ (EW10A) | 103 | 1997 |
PEUGEOT 307 CC (3B) |
||||
| 1.6 16V | 2003 - 2009 | NFU (TU5JP4) | 80 | 1587 |
| 2.0 16V | 2003 - 2005 | RFN (EW10J4) | 100 | 1997 |
| 2.0 16V | 2003 - 2009 | RFK (EW10J4S) | 130 | 1997 |
| 2.0 16V | 2004 - 2009 | RFJ (EW10A) | 103 | 1997 |
PEUGEOT 807 (EB_) |
||||
| 2.0 | 2002 - súčasnosť | RFN (EW10J4) | 100 | 1997 |
| 2.2 | 2002 - súčasnosť | 3FZ (EW12J4) | 116 | 2230 |
PEUGEOT 607 (9D, 9U) |
||||
| 2.0 | 2000 - 2005 | RFN (EW10J4) | 100 | 1997 |
| 2.2 16V | 2000 - 2005 | 3FZ (EW12J4) | 116 | 2230 |
| 2.2 16V | 2005 - 2010 | 3FY (EW12J4) | 120 | 2230 |
| 2.2 HDi | 2000 - 2006 | 4HX (DW12TED4) | 98 | 2179 |
| 2.2 HDi | 2006 - 2010 | 4HS (DW12BTED4), 4HT (DW12BTED4) | 125 | 2179 |
PEUGEOT 407 SW (6E_, 6D_) |
||||
| 2.0 | 2004 - 2005 | RFN (EW10J4) | 100 | 1997 |
| 2.2 | 2004 - 2005 | 3FZ (EW12J4) | 116 | 2230 |
| 2.2 16V | 2005 - 2010 | 3FY (EW12J4) | 120 | 2230 |
PEUGEOT 407 (6D_) |
||||
| 2.0 (6DRFNB, 6DRFNE) | 2004 - 2005 | RFN (EW10J4) | 100 | 1997 |
| 2.2 (6D3FZE, 6D3FZH) | 2004 - 2006 | 3FZ (EW12J4) | 116 | 2230 |
PEUGEOT PARTNER Großraumlimousine (5_, G_) |
||||
| 2.0 HDI | 2000 - 2008 | RHY (DW10TD) | 66 | 1997 |
| 2.0 HDi 4x4 | 2004 - 2005 | RHY (DW10TD) | 66 | 1997 |
PEUGEOT PARTNER Kasten/Großraumlimousine (5_, G_) |
||||
| 2.0 HDi | 2000 - 2008 | RHY (DW10TD) | 66 | 1997 |
| 2.0 HDi 4x4 | 2004 - 2005 | RHY (DW10TD) | 66 | 1997 |
PEUGEOT PARTNER Pritsche/Fahrgestell (5_, G_) |
||||
| 2.0 HDi | 2002 - 2008 | 66 | 1997 | |
PEUGEOT 206 CC (2D) |
||||
| 2.0 S16 | 2000 - 2007 | RFN (EW10J4) | 100 | 1997 |
PEUGEOT 407 Coupe (6C_) |
||||
| 2.2 16V | 2005 - súčasnosť | 3FY (EW12J4) | 120 | 2230 |
SUZUKI |
||||
SUZUKI LIANA Schrägheck |
||||
| 1.4 DDiS | 2004 - 2007 | 8HY | 66 | 1398 |
SUZUKI LIANA (ER, RH_) |
||||
| 1.4 DDiS (RH 414D) | 2004 - súčasnosť | 8HY | 66 | 1398 |
TOYOTA |
||||
TOYOTA AYGO (_B1_) |
||||
| 1.4 D-4D (WNB10_, WNB10R) | 2005 - 2010 | 2W-ZTV | 40 | 1398 |
